• Locates the edges of wood or metal studs up to ¾ inch (19 mm) deep
• New "Ready" light indicates when calibration has completed successfully
• New "Edge" light indicates when the tool is over a stud edge
• Updated SpotLite® Pointer shines an arrowshaped light on the wall to mark the target
• Should scanning begin over a stud, Zircon's patented "over-the-stud" indicator alerts the user to start the scan in a new location
• Ergonomic design can be comfortably held in either hand at any angle

• Battery Type 9V alkaline (not included)
• Dimensions 5.33 in. H x 2.14 in. W x 1.34 in. D (136 mm x 55 mm x 34 mm)
• Weight 2.0 oz. (56.3 g) without battery

Position Accuracy*

• Wood studs: Typically within ¹⁄₈ in. (3 mm) using the dual scan and mark procedure
• Metal studs: Typically within ½ in. (13 mm) using the dual scan and mark procedure

Depth*

• Typically up to ¾ in. (19 mm)

Splash and water resistant, not Resistance waterproof

*NOTE: See tool's instructions for more information. Sensing depth and accuracy can vary due to moisture, content of materials, wall texture, paint, etc.

Indoor use only

This product is covered by Zircon’s Limited Lifetime Warranty for the United States and Canada.
