• StudScan Mode locates the edges of wood and metal studs up to 3⁄4 in. (19 mm) deep
• DeepScan® Mode doubles the scanning depth to locate the edges of wood and metal studs up to 11⁄2 in. (38 mm)
• WireWarning® Detection indicates the presence of live unshielded AC electrical wiring up to 2 in. (50 mm) deep in both stud scanning modes
• Zircon’s patented "over-the-stud" feature alerts the user if scanning begins over a stud SpotLite®Pointer shines an arrow-shaped light on the scanned surface to clearly indicate the location of the target
• Translucent base and illuminated "V" marker groove provides more accurate marking of target location
• Ergonomically designed grip allows a comfortable hold on the tool for any size hand at any angle

• Battery Type 9V alkaline required (not included)
• Dimensions 6.77 in. H x 2.87 in. W x 1.65 in. D (172 mm x 73 mm x 42 mm)
• Weight Weight 4.80 oz. (136 g) without battery

Depth*

• StudScan mode: Up to ¾ in. (19 mm)
• DeepScan® mode: Up to 1 ½ in. (38 mm)

WireWarning® Position Accuracy*

Typically 90-250 V at 50-60Hz within 6 in. (152 mm) of a hot unshielded wire in drywall

WireWarning® Depth*

In typical wall with Romex® wiring, wire can be detected up to 2 in. (51 mm) deep

• Splash and water resistant, not waterproof
• *NOTE: Sensing depth and accuracy can vary due to moisture, content of materials, wall texture, paint, etc.
• Not recommended for use on lath and plaster.
• Indoor use only

This product is covered by Zircon’s Limited Lifetime Warranty for the United States and Canada.
